Fiber-coupled single-mode laser diode at 1000nm
Fiber-coupled single-mode laser diode at 1000nm
SML1000B50YY250MXXXX
Mean wavelength: 1000 nm
Output power: 250 mW
Forward current: 450 mA
Forward voltage: 1.7 V
Threshold current: 25 mA
Spectrum bandwidth (3dB): 0.2 nm
Polarization extinction ratio: 17 dB
Slow axis beam divergence: deg
Fast axis beam divergence: deg
Package: Fiber-coupled
