ProductsOptical AmplifiersSemiconductor Optical Amplifiers (SOA)Semiconductor optical amplifier at 954nm in BTF package
Semiconductor optical amplifier at 954nm in BTF package
Semiconductor optical amplifier at 954nm in BTF package
SOA095480YY25DBXXXX
Wavelength: 954 nm
Gain bandwith (3dB): 80 nm
Small signal gain: 25 dB
Saturation output power: 17 dBm
Noise figure: 6.5 dB
Forward current: 500 mA
Forward voltage: 1.7 V
Polarization extinction ratio: 15 dB
Package: Fiber-coupled
Add to cart
applications
- Scientific
- Tunable laser source
- External cavity laser
